CTCP Computer Board Making Machine 28pcs/H 1160x960mm Maximum Output

CTCP Computer Board Making Machine 28pcs/H 1160x960mm Maximum Output
CTCP Computer Board Making Machine 28pcs/H 1160x960mm Maximum Output
CTCP Computer Board Making Machine 28pcs/H 1160x960mm Maximum Output CTCP Computer Board Making Machine 28pcs/H 1160x960mm Maximum Output

Gambar besar :  CTCP Computer Board Making Machine 28pcs/H 1160x960mm Maximum Output

Detail produk:
Tempat asal: SHENZHEN
Nama merek: PLATE-CD
Nomor model: CD-64V
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1
Harga: $13000-$23000
Kemasan rincian: Kotak kayu ekspor standar
Waktu pengiriman: 8 hari
Syarat-syarat pembayaran: T/T
Menyediakan kemampuan: 20 unit/bulan
Kontak

CTCP Computer Board Making Machine 28pcs/H 1160x960mm Maximum Output

Deskripsi
Kondisi: Mesin Bekas Waktu manufaktur: 2019 tahun
Keluaran maksimal: 1160*960mm Kuantitas Keluaran: 28 buah / jam
Berat: 900kg Voltase: 220V
Menyoroti:

CTCP Computer Board Making Machine

,

1160x960mm Board Making Machine

,

28pcs/H CTCP Printing Machine

CTCP board making machine, CTCP computer board making machine, UVCTP computer board making machine



Mode CD-32V CD-48V CD-64V CD-32R CD-48R CD-64R
Exposing Method External Drum
Imaging System 32-channel 48-channel 64-channel 32-channel 48-channel 64-channel
Discrete 400-410nm laser Discrete 830nm laser
Output Speed 16 plates/hour 24 plates/hour 28 plates/hour 16 plates/hour 24 plates/hour 28 plates/hour
1,030×800mm 2,400dpi
Plate Size Max.1,130×920mm,Min. 400×300mm
Exposing Size Max.1,130×904mm
Media Type UV plate, high-sensitive PS plate Thermal plate
Plate Thickness 0.15mm~0.3mm
Resolutions 2,400dpi
Repeatablity ±5μm(Continuous exposure over four times on the same plate with a temperature of 23°C and 60% RH )
Interface USB2.0/USB3.0(Recommended option is USB2.0)
Plate Loading First manual, then autoload
Net Weight 900KG
Device Size 2,530×1,050×950mm(W×D×H)
Power supply Single phase:200V-240V; Max power(Peak value):4KW
Environment Recommended temperature: 21-25°C Allowable temperature: 18-26°C Humidity: <70%
